5G mmWave AAU

The system supports a maximum of hundreds of micro-RRU units Flexible and fast networking, the network management system can be integrated with the macro network to meet various hot spot coverage needs High integration, small size, light weight, easy to install and use High antenna gain, strong anti-interference ability, low delay, high-precision positioning
5G mmWave AAU
Description Features Networking Specifications Related Products

The 5G mmWave AAU is a Active Antenna Unit in the XLink™ 5G mmWave distributed small cell solution. It is designed to be used directly with baseband unit (BBU) or in conjunction with the expansion unit (rHUB/EU) to provide 5G wireless signal coverage.

The 5G mmWave AAU can be deployed remotely using fiber optic extension, making it ideal for indoor coverage scenarios.



Features:

Energy-efficient design

High integration, small size & lightweight

Flexible and fast networking

Supports full-format IoT expansion services

High-gain antenna, strong anti-interference, low latency, and high-precision positioning



Networking:



Specifications:

Items

Index

Frequency

24.25GHz-29.5GHz(N257/N258)

Channels

2T2R

Duplexing

TDD

Radio Frequency Bandwidth

2.75GHz

Carrier Bandwidth

200MHz

Modulation

DL: QPSK/16-QAM/64-QAM/256-QAM

UL: BPSK/π/2-BPSK / QPSK/16-QAM/64-QAM

Antenna Polarization

45 ° dual polarization phased array

Beam Scanning Range

8 horizontal wave positions/single radiation surface, scanning range of ±45° (center frequency based)

4 horizontal wave positions/single radiation surface, scanning range of ±45° (center frequency based)

Weight

2.5kg

Dimension

217.5×222.5×61mm

Energy-efficient design

High integration, small size & lightweight

Flexible and fast networking

Supports full-format IoT expansion services

High-gain antenna, strong anti-interference, low latency, and high-precision positioning

Items

Index

Frequency

24.25GHz-29.5GHz(N257/N258)

Channels

2T2R

Duplexing

TDD

Radio Frequency Bandwidth

2.75GHz

Carrier Bandwidth

200MHz

Modulation

DL: QPSK/16-QAM/64-QAM/256-QAM

UL: BPSK/π/2-BPSK / QPSK/16-QAM/64-QAM

Antenna Polarization

45 ° dual polarization phased array

Beam Scanning Range

8 horizontal wave positions/single radiation surface, scanning range of ±45° (center frequency based)

4 horizontal wave positions/single radiation surface, scanning range of ±45° (center frequency based)

Weight

2.5kg

Dimension

217.5×222.5×61mm
