Unity™ Outdoor Integrated Base Station 5W

This product is based on the advanced multi-core ARM and FPGA scheme, and adopts the integrated design of 5G BBU and RRU to realize the complete 5G NR wireless access network function, which can quickly and quickly establish a 5G wireless network with large bandwidth, low delay and high reliability for users. This product has the advantages of low power consumption, small size, convenient engineering construction, and is especially suitable for 5G+ vertical industry applications such as intelligent manufacturing, smart mining, and smart parks.

Download

Unity™ Outdoor Integrated Base Station 5W

Description Features Networking Specifications

SageRAN Unity™ 5G Integrated Base Station leverages the NXP LX2160A platform, featuring low power consumption, easy customization, and high integration capabilities. It is ideal for industry-specific applications and boosts wireless network performance in rural areas with limited operator or carrier coverage.

This compact base station integrates the 5G baseband module and radio module, pre-installed the SageRAN`s Engine™ 5G L2 L3 software, to provide a high performing 5G wireless access network.

Features:

Energy Saving: Power consumption less than 300W

Quick Installation: No need for server room or air conditioner, easy to install

Rapid Response: Supports quick deployment and rapid to set 5G network

Waterproof & Dustproof: Protection degree: IP65

Agile Scalability: Supports gNB cascading and RRU expansion

Cost & Efficiency Promotion: Reduces construction and maintenance costs, improves efficiency

Networking:

Specifications:

Items	Index	Items	Index
Duplexing	NR TDD	Peak Rate DDDSUDDSUU	Support multi subframe ratios
Frequency	N78/N79	Peak Rate DDDSUDDSUU	UL 1.0Gbps , UL 300Mbps
IBW	40MHz/60MHz/100MHz	Sync.	GPS/ BeiDou /1588v2(Optional)
Modulation	256QAM/256QAM(DL/UL)	Antenna	External Antenna
Cell No.	1x100MHz 4T2R cell	Power supply	AC 220V
Output Power	4 x5W (Power rates customizable)	Power Consumption	< 240W
Activated users	≥ 200/cell	Dimension	340×285×143mm
Connected users	≥ 400/cell	Weight	< 13.5 kg
